Micro switches, also known as snap-action switches, are widely used in industrial, automotive, and home appliances due to their fast switching action, compact size, and reliability. These switches are actuated by a small physical force, and they make or break a circuit with minimal travel distance. There are several different types of micro switches, each designed for specific applications.
Single Pole Single Throw (SPST) Micro Switch: This is the most common type of micro switch. It has one input terminal (Common) and one output terminal (Normally Open or Normally Closed). It can be used for simple on/off switching.
Single Pole Double Throw (SPDT) Micro Switch: This type has one input terminal and two output terminals, allowing the switch to choose between two different circuits (Normally Open and Normally Closed). It’s more versatile than the SPST switch and can be used for more complex control functions.
Double Pole Double Throw (DPDT) Micro Switch: A less common type, this switch has two independent input terminals and two sets of output terminals, offering even more flexibility in controlling multiple circuits at once.
● Plunger Actuated Micro Switch: The switch is activated when a plunger (a push button or pin) is pressed. This type is often used in applications where direct, linear force needs to be applied to the switch.
Applications: Automotive systems, security devices, and door sensors.
● Roller Actuated Micro Switch: A roller is used to actuate the switch. It is typically used in applications where continuous motion or intermittent contact is needed. The roller can be mounted on a lever or arm and can be activated by a moving object.
Applications: Conveyor belts, elevator systems, and position detection systems.
● Lever Actuated Micro Switch: This type uses a lever to activate the switch. The lever can be designed for different travel lengths and can be positioned to suit specific mechanical designs.
Applications: Pressure-sensitive equipment, machine guarding, and appliances.
● Pin Plunger Actuated Micro Switch: Similar to a plunger, the activation mechanism involves a pin that can be pushed in. These types are often used when a push-pin mechanism is needed for activation.
Applications: Limit switches, and control systems.
Basic Push Button Actuation: A simple mechanical push button that activates the switch. These are the simplest actuator forms and are often used in consumer products like appliances and toys.
● Temperature-Sensitive Micro Switches: These are micro switches with built-in temperature sensors, often used in applications where the switch is required to respond to specific temperature conditions.
Applications: Temperature regulation in appliances (e.g., refrigerators, ovens), industrial heating systems.
● Waterproof or Sealed Micro Switches: These micro switches are designed with protective coatings or sealing mechanisms to prevent ingress of water, dust, or other contaminants. They are crucial in harsh environments.
Applications: Marine applications, outdoor equipment, or automotive use.
● Tilt Switch Micro Switches: These micro switches activate when tilted, often used in applications where the orientation of an object is important, such as level detection or position sensing.
Applications: Mobile equipment, automotive systems, and battery-powered devices.
● Subminiature Micro Switches: These are smaller, more compact versions of standard micro switches, designed for applications where space is limited.
Applications: Portable electronics, medical devices, and precision equipment.
● Long Stroke Micro Switches: These switches are designed to handle more significant movements or distances before activation. They are often used when more precise or extended actuation is required.
Applications: Heavy machinery, large-scale automation systems.
● Micro switches come in many forms, each designed to meet the specific needs of different applications. They are available with a variety of actuators (plunger, roller, lever, etc.), electrical configurations (NO, NC, SPDT, etc.), and environmental features (waterproof, subminiature, temperature-sensitive). Their versatility, durability, and reliability make them essential components in many industries, including automotive, manufacturing, robotics, and home appliances.
